Yihetai Cable is a professional and trusted wire and cable manufacturer with over 20 years of rich experience in the industry. Leveraging our decades of technical expertise and manufacturing proficiency, we are fully committed to delivering premium-quality wires and cables. At the same time, we strive to exceed customer expectations at every stage—from product development to after-sales service—ultimately maximizing customer satisfaction and building long-term cooperative relationships.
With UL 1007 Wire as a flagship product in our single-conductor lineup. This thermoplastic-insulated wire is part of our extensive product portfolio, which also includes other single-conductor solutions (UL1015, UL1569, UL1571, etc.), multi-conductor cables (AWM Style 2464, UL2468, UL2651, etc.), as well as network cables and high-temperature wires.
Compliant with strict UL and CUL standards, our UL 1007 Wire is a reliable choice for a wide range of industries, such as household appliances, medical devices, automotive, robotics, electronics, and renewable energy.
Guided by the principles of customer-centricity, employee well-being, and social responsibility, Yihetai Cable embraces innovative thinking as a core value. Dedicated to becoming a customer-trusted enterprise, we embody our commitment to high-quality, industry-compliant solutions through our UL 1007 Wire.
| Product | ul 1007 wire |
| Copper Conductor | 32 AWG - 16 AWG, Solid or Stranded. |
| Style | Single conductor with extruded insulation |
| Rating | 80 deg C, 300 Vac, Horizontal flame. Optional - 60 deg C or 80 deg C Oil. |
| Standard | Appliance Wiring Material UL 758. |
| Insulation | Extruded PVC |
| Marking | General. |
| Application | Internal wiring of appliances. Tags may indicate the following: 600 V Peak - For Electronic Use Only. |
| Package | 305M/Roll; 610M/Roll |
| Insulation | Extruded PVC. |
| Conductor | Insulation | Max.Cond Resistance | Unit Length | |||
| Size(AWG) | Construction（No./mm) | Diameter(mm) | Nominal Thickness (mm) | Diameter(mm) | (Ω/km) | (M)(Ft) |
| 32 | 7/0.08 | 0.24 | 0.38 | 1 | 542 | 610/2000 |
| 30 | 7/0.10 | 0.3 | 1.06 | 347 | ||
| 28 | 7/0.127 | 0.38 | 1.14 | 218 | ||
| 26 | 7/0.16 | 0.48 | 1.24 | 138 | ||
| 24 | 11/0.16 | 0.61 | 1.37 | 85.9 | 305/1000 | |
| 22 | 17/0.16 | 0.76 | 1.52 | 54.3 | ||
| 20 | 21/0.18 | 0.95 | 1.71 | 33.9 | ||
| 18 | 34/0.18 | 1.21 | 1.97 | 21.4 | ||
| 16 | 26/0.254 | 1.50 | 2.26 | 13.5 | ||
