24 Pin Ribbon Cable 1.27mm IDC Cable Assembly Grey Flat Cable
price
US $0.20 - US $1.88 / pieces
YHT-031
EXW, FOB
100 pieces
15000pieces / Month
China
20Day
Quantity
24 Pin Ribbon Cable 1.27mm IDC Cable Assembly Grey Flat Cable
• OEM 24 Pin Ribbon Cable, Passes UL VW-1 & CSA FT1 vertical flame test, quality assurance.
• Uniform insulation thickness of wire to ensure easy stripping and cutting of the IDC Cable Assembly.
• Customzied 24 Pin Flat Ribbon Cable, IDC Cable Assembly for Screen Display
• Data Transmission 24 Pin Flat Ribbon Cable, Good Stability
• 100% UL Standard 24 Pin Ribbon Cable, Custom Length, Color, Wire Specifications
• 24 Pin Ribbon Cable, IDC Cable Assembly, 24 Pin Flat Ribbon Cable
| Produce | 24 Pin Flat Ribbon Cable |
| Housing space | 1.27mm, or 1.0mm 2.0mm 2.54mm |
| Specification of Wire | UL2651 28Awg, or 32awg, 30awg, 26awg, 24awg |
| Copper Wire | Tinned copper wire |
| Conductor | Tinned or Bare, Stranded or Solid Copper |
| Copper core conductor | 7 / 0.12mm |
| Color | Gray with red edge and printing or customized |
| Rated Voltage | 300V |
| working temperature | - 40°C~+105°C |
| Conductor diameter | 0.12±0.005mm |
| Insulator thickness | Minimum 0.10mm, average 0.23mm |
| Wire diameter thickness | 0.9±0.05mm |
• OEM 24 Pin Ribbon Cable, Passes UL VW-1 & CSA FT1 vertical flame test, quality assurance.
• Uniform insulation thickness of wire to ensure easy stripping and cutting of the IDC Cable Assembly.
• Customzied 24 Pin Flat Ribbon Cable, IDC Cable Assembly for Screen Display
• Data Transmission 24 Pin Flat Ribbon Cable, Good Stability
• 100% UL Standard 24 Pin Ribbon Cable, Custom Length, Color, Wire Specifications
• 24 Pin Ribbon Cable, IDC Cable Assembly, 24 Pin Flat Ribbon Cable
